Hyundai iLoad Turbocharger Failure Due To Overspeeding

Hyundai iLoad Turbocharger Failure Due To Overspeeding

The Turbocharger Failure Seems To Be a Common Issue For Hyundai Iload/Imax 2.5L Diesel.

We Have Supplied And Fitted Iload Turbochargers For Our Customers Over Many Years And We Found That Turbo Overspeeding Is The Most Common Problem That Occurs, This Causes Turbo Failure By Damaging The Turbine Wheel, Compressor Wheel, Bearings And VNT.

Below Are Examples Of Iload Turbo Overspeeding Caused By Intake Restrictions And Or Boost Leaks In The Charge Piping System/ Intercooler. The Turbo Is Going To Try To Get Requested Boost Via The ECU & Boost Controller, Which Makes The Wheel Spin Almost Twice As Fast (120,000RPM+) And It Eats The Trust Bearing,Compressor Wheel, Turbine Wheel And Variable Vanes.

iload intercooler leaking oil



iload turbo trust bearing iload turbo turbine wheel

We Found Massive Amounts Of In & Out Shaft Play Before Pulling The Turbo Apart. As You Can See From The Photos, Trust Bearing Was Worn Out, Turbine Wheel Was Chipped And Variable Vanes Were Damaged.

Here At CCT Turbo, We Analyse The Original Turbo Problem Before Replacing The Turbo. Then We Repair It Accordingly To Prevent Our Customer From Having The Turbo Failed Again. You Never Go Wrong With Us!
